Request For Our Latest Prices On ZERON 100 Bolts in Manama, Bahrain!
Malik Fasteners, a reputable manufacturer and supplier located in Manama, Bahrain, is well-known for providing top-notch fastening solutions, including their high-quality ZERON 100 Bolts. With a strong focus on quality and reliability, the company produces bolts that are designed to endure tough industrial environments. Their ZERON 100 Bolts are crafted using cutting-edge production methods and rigorous quality control to guarantee exceptional strength, corrosion resistance, and long-lasting durability. Catering to industries like marine, chemical processing, oil & gas, and desalination, Malik Fasteners offers tailored fastening products that meet international standards. Their customer-focused approach makes them a go-to partner for critical applications.
ZERON 100 Bolts are made from a super duplex stainless steel alloy that includes about 25% chromium, 7% nickel, 3.6% molybdenum, and 0.25% nitrogen, along with copper and tungsten to boost corrosion resistance. This well-balanced composition ensures excellent strength and protection against pitting and crevice corrosion. On the mechanical side, ZERON 100 Bolts deliver high tensile and yield strength, remarkable toughness, and impressive fatigue resistance. Their outstanding mechanical stability, even in challenging conditions, makes them perfect for high-pressure, high-temperature, and chloride-rich applications across various industrial sectors.
| % | Cr | Ni | Mo | Cu | W | C | N | Mn | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Min | 24 | 6 | 3 | 0.5 | 0.5 | – | 0.2 | – | – | – | – | – |
| Max | 26 | 8 | 4 | 1 | 1 | 0.03 | 0.3 | 1 | 1 | 0.030 | 0.010 | Balance |
| Mechanical & Physical Properties | -70°C | -46°C | 21.1 °C | 93.3°C | 148.9 °C | 204.4 °C | 250 °C | 300°C |
|---|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength, MPa | – | – | 750 | 670 | 620 | 610 | 600 | 590 |
| 0.2% Yield Strength, MPa | – | – | 550 | 430 | 400 | 380 | 370 | 360 |
| Reduction of area % | – | – | – | – | – | – | – | – |
| Elongation % | – | – | 25 | – | – | – | – | – |
| UNS S32760 Fg Bolts, Studs Threads: | METRIC, BSW, BSF, UNC, UNF or as required |
|---|---|
| Zeron 100 Threaded Rod Standard: | ANSI – American National Standards Institute
|
| Zeron 100 Fasteners Material Specification | Zeron 100 Fasteners , UNS S32760 Bolts |
| S32760 Fasteners / Bolts Standard | DIN, UNI, ISO, JIS, GB, IS, BS, ASME, ANSI, ASTM and all International Standards |
| 1.4501 UNS S32760 Fasteners/ Bolts Size | M2, M2.5, M3, M4, M5, M6, M8, M10, M12, M14, M16, M20, M24, M30, M36 to M160 |
| Length of S32760 Hex Bolt | 3 mm to 200 mm |
| Source of raw materials to manufacture 1.4501 UNS S32760 Screw | Tata Steel, JSPL, RINL, Usha Martin, Dhamm Steel, Mukund Steel etc. |
| Zeron 100 Hex Bolt Thread | Metric Coarse |
| S32760 bolting Test Certificate: | Manufacturer Test Certificate as per EN 10204 / 3.1 |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Our ZERON 100 Bolts are meticulously packaged to ensure utmost protection during transit, especially for international exports. They are securely housed in robust wooden boxes or cases, conforming to stringent international standards for packaging. Each bolt is prominently marked with our trademark (Company’s LOGO), detailing the Grade, Size, and Lot No. Upon request, we provide customizable product markings to meet specific client needs. Moreover, we furnish comprehensive documentation including Manufacturer Test Certificates compliant with EN 10204-3.1 and EN 10204-3.2, Raw Materials Certificates, NABL approved Lab Test Reports, 100% Radiography Test Reports, as well as Third Party Inspection Reports, ensuring the highest quality assurance for our esteemed customers.
